The Lynx 3.0 , redefining entry-level thermal imagers.

The HIKMICRO Lynx 3.0 LH35 represents the pinnacle of thermal monocular performance for serious professionals. Featuring a 384x288 thermal detector and a 35mm F1.0 lens, it delivers 3.4x base magnification, a 7.5° field of view, and a detection range of up to 1800 metres, making it the ultimate tool for long-range observation.

Incorporating AI-driven Image Pro 3.0 and Zoom Pro algorithms, the LH35 offers superior image fidelity and consistency across challenging conditions. The HSIS shutterless technology enables smooth, silent operation for continuous, distraction-free imaging.

At 354.5 grams, the LH35 remains portable yet robust. A replaceable 18650 battery provides up to 4.5 hours of operation at -20°C, ensuring dependable field endurance. Ideal for hunting, security, or professional surveillance, it delivers unmatched clarity and control.

• Image Sensor VOx Uncooled Focal Plane Arrays
• Max. Resolution 384 × 288
• Frame Rate 50 Hz
• Pixel Interval 12 μm
• Response Waveband 8 μm to 14 μm
• NETD Less than 15 mK (@25°C), F#=1.0
• Lens (Focal Length) 35 mm, F1.0
• Focus Mode Focus Wheel
• Min. Focusing Distance 3.5 m
• Magnification 3.4 × - 27.2 × (8×)
• Field of View (H × V), Degrees / m @100 m 7.5° × 4.6° / 13.1 m × 8.0 m
• Detection Range 1800 m
• Display 1920 × 1080, 0.49 inch, AMOLED
• Contrast Adjustment Yes
• Brightness Adjustment Yes
• Palettes Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome
• Exit Pupil 6 mm
• Eye Relief 20 mm
• Diopter (Range) -5 D to +3 D
• Tone Adjustment Cold, Warm
• Zoom Pro Yes
• HSIS (HIKMICRO Shutterless Image System) Yes
• Image Pro 3.0 Yes
• Sync Pro Yes
• Battery Type Replaceable and rechargeable 18650 battery
• Protection Level IP67
• Weight 354.5 g with Battery

• 384×288 thermal detector with NETD < 15 mK
• 35mm F1.0 lens with 1800m detection range
• AI-powered Image Pro 3.0 and Zoom Pro algorithms
• HIKMICRO Shutterless Image System (HSIS)
• 0.49” 1920×1080 AMOLED display
• Up to 4.5 hours’ operation at -20°C
• Lightweight, pocket-sized 354.5g design

• 1 x Lynx 3.0 Thermal Monocular
• 1 x Quick Start Guide
• 2 x 18650 Battery
• 1 x Type-C USB Cable
• 1 x Battery Charger
• 1 x Lint Free Cloth

• Main Unit: 3 Years

If you're after any lost parts such as lens covers or eye pieces for your unit, Hik Micro now have a spares page which can be found at https://www.hikmicroassist.co.uk/
