HIK Micro Lynx 6mm 35mK 384×288 17um Smart Thermal Monocular

£369.00 (ex. VAT: £307.50)

HIK Vulkan 6mm 35mK Smart Thermal Monocular

The HIK Vision Vulkan 6mm delivers a high-quality thermal image and packs a host of features normally reserved for high-end thermal spotters.

The 160x120px, 17µm thermal sensor (35mK NETD Rating) and HIK software delivers a detailed image to the screen. The WiFi and dedicated app allows you to take complete control of the unit’s settings and features from your smartphone.

1 in stock

HIK Vision Authorized Dealer





HIK Micro Lynx 6mm 35mK 384x288 17um Smart Thermal Monocular

The

HIK Micro Lynx

6mm delivers a high-quality thermal image and packs a host of features normally reserved for high-end thermal spotters.

The 160x120px, 17µm thermal sensor (35mK NETD Rating) and HIK software delivers a detailed image to the screen. The WiFi and dedicated app allows you to take complete control of the unit's settings and features from your smartphone.

35mK NETD Rating = One of the most sensitive sensors available on the market, detecting even the smallest temperature differences!

IP67 rating guarantees a robust chassis capable of repelling dust and rain, protecting you from the worst of the weather.

Battery life = 10hrs of continuous running!

This is all backed up by a 3 year UK warranty.

HIK Micro Lynx 6mm 35mK 384x288 17um Smart Thermal Monocular

MAIN
Sensor 160×120px @ 17µm
Objective Lens 6mm
Detection Range (Vehicle 1.4 x 4m) 559m
Detection Range (Human 1.8 x 0.5m) 182m

SENSOR
Type Vanadium Oxide Uncooled Focal Plane Arrays
Resolution, pixels 160×120 px
Pixel pitch, µm 17µm
Frame rate, Hz 50 Hz
NETD Rating 35mK

OPTICS
Objective lens F1.1
Magnification (Optical) 0.6x
Magnification (Digital) 1x, 2x, 4x,
Field of view 24.7° × 18.7° (H × V)

DISPLAY
Type 5.08mm, LCOS
Resolution, Pixels 720 × 540
Colour Palettes Black Hot, White Hot, Red Hot, Fusion

VIDEO & SOUND
Video Recorder YES
Sound Recorder NO
Build in memory, Gb 8 Gb

ADDITIONAL FEATURES
Hot Tracking YES
WiFI hot spot YES
T-Vision App support YES

ENVIRONMENTAL
Degree of protection, IP code IP67
Dust protection Protected against dust ingress
Water protection Protected against temporary submersion in water
Operating temperature range -20 °C to 55 °C

WEIGHT & SIZE
Dimensions, mm 158 mm × 61 mm × 57 mm
Weight, kg 0.25 kg

POWER SUPPLY
Operating time on battery
(WiFi & Hot tracking disabled) 10 hours continuous running
Charging interface USB-C
Battery capacity after 1000 cycles 80%

HIK Micro Lynx 6mm 35mK 384x288 17um Smart Thermal Monocular

HIK VISION THERMAL SENSOR

HIK Micro Lynx

160x120px, 17µm thermal sensor with a NETD rating of 35mK produces a high quality thermal image.

35mK NETD Rating = One of the most sensitive sensors available on the market, detecting even the smallest temperature differences!

Combine this with the HIK software that processes the image you see on screen and you have an unbeatable package that performs well above its price point.

T-VISION APP: Connect – Control – Stream

Connect your smartphone and take control of all features of the

HIK Micro Lynx

The T-Vision app allows you to stream the output in real time allowing you to share your viewpoint with a friend.

You can also record images and video, optimise the colour profile, display settings and magnification all from the easy to use app.

HOT TRACK

Activate Hot Tracking and your

HIK Micro Lynx

will highlight the hottest spot detected in the current frame with a green crosshair.

This is useful to highlight small heat sources as you scan around.

This feature can also be deactivate in the menu or controlled in the App.

Brand HIK VISION
Popularity

HIK Micro Lynx 6mm 35mK 384x288 17um Smart Thermal Monocular

SKU HIKVUL6
Unit Type Thermal
Colour Palettes Yes
Detection Range 550m
Display Resolution 720x540
Display Type LCOS
FOV @ 100 yards 24°
Magnification (Digital) 4x
Magnification (Optical) 0.6x
NETD <35mK
Objective Lens Diameter 6mm
Operating Temperature -20/+40°C
Pixel Pitch 17μm
Rangefinder Stadiametric
Refresh Rate 50HZ
Sensor Resolution 160x120
Video / Sound Recording Yes
Wi-Fi Yes
Manuals

HIK Micro Lynx 6mm 35mK 384x288 17um Smart Thermal Monocular

Download the HIK App here:

Apple: https://apps.apple.com/us/app/t-vision/id1478705944

Android: https://www.app-st.net/ZdMM

The ultimate companion for your HIK Micro by HIK Vision Vulkan Smart Thermal Monocular - Double the battery life of your Vulkan!

The WULF 4 Portable Power Pack is a powerful and fully implemented powerbank with a stylish flashing battery indicator, torch function and 2 built-in lithium batteries (4000mAh/3.7V).

With the WULF 4 Power Pack, you will now be able to charge your Smartphone, Tablet, Digital Camera, GPS... and even your HIK Vulkan Thermal Monocular (and similar LRF, Night Vision and Thermal devices).

Modern, sleek, easy-to-use, and with the included 1m USB/micro USB charging cable, dead batteries in the field will be a thing of the past.

Battery: 2x Built-In Lithium (4000mAh/3.7V)
Input: 5V-1A
Output: 5V-2.1A
LED Torch: 1x
USB Port: 1x
Micro USB Port: 1x
Material: Plastic
Length: 10.00 cm.
Width: 4.50 cm.
Height: 2.60 cm.
Weight: 135.00 g.

When you divide the power of the PowerCharger (mAh) by the capacity of the battery in your mobile device (mAh), you know approximately what percentage or how often you can charge your mobile device.
